Specsification Ultrasonic Pilse Velocity UPV Proceq Pundit Lab+

- Bandwidth : 20 to 500 kHz
- Technology : Ultrasonic pulse velocity
- Measuring Resolution : 0.1 us
- Pulse Voltage : ±125 to ±500 V (UPV)
- Receiver Gain : 1x, 10x, 100x, AUTO, Pundit Lab+ up to 1000x
- Nominal Transducer Frequency : 24 – 500 kHz
- Pulse Shape : Square Wave
- Pulse Delay : –
- Number of Channels : 1
- PC Software : Pundit Link unlocks the full Pundit Lab+ capabilities
- Display : 79 x 21 mm passive matrix OLED
- Memory : > 500 measured values
- Connections : USB connection to PC
- Measurement Modes :
Pulse velocity
Surface velocity
Data logging
E-modulus
Compressive strength correlation
Crack depth
- Measuring Range : Up to 15 m depending on concrete quality
- Special Features :
Open interface
Integrated amplifier gain stage
Real time stamp
- Transducers :
Avaiable Proceq transducers: 54 kHz, 150 kHz, 250 kHz, 54 kHz Exponential, 500 kHz and 250 kHz Shear Wave
Connect third party transducers up to 24 kHz, 54 kHz, 150 kHz, 250 kHz, 54 kHz Exponential, 500 kHz and 40 kHz shear wave dry point contact

Ultrasonic Pulse Velocity Proceq UPV Pundit Lab (+)

A flexible UPV test instrument designed for laboratory operations
Specifically designed for laboratory usage
Can be integrated into 3rd party software e.g. LabView
Removes the need for external amplification when used with exponential transducers

Tes UPV Proceq Pundit Lab+ dapat digunakan Untuk :

- Mengetahui keseragaman kualitas beton
- mengetahui kualitas struktur beton setealh umur beberpa tahun
- mengetahui kekuatan tekanan beton

Applications Proceq Pundit LAB (+):

Correlation of compressive strength of concrete and rocks / Correlation to modulus of elasticity of rocks / Mapping homogeneity of concrete / Concrete strength estimation using the SONREB method
